Beveling Machines

SKE PHB-grinding beveling,designing  machine with 200x40x5mm metal bond diamond disc ,it can use for all types small (1 -24 inches)Shape glass hand processing ALL IN 1 MACHINE ,like dhar polish,half/full round,45',Tukdi edging beveling work, designing etc With Changing diamond disc/ wheel rough/fine/polish any kind of small glass shape like  straight,round,oval,capsule  wave etc. And any 3mm to 25mm thickness  with water on horizontal table with surrounding tank for water collection and recycling  Available with 2 motots hand and cnc type with 100mm to 350mm metal bond diamond discs,and also in electroplated diamond discs in up to 24 inches diameters. for more details please contact us, we can make as per your requierment and sutability ..

Additional Information:

• Production Capacity: 1000 PCS PER YEAR

SKE-11B(34HP)semiautomatic  straight line edge bevel grinding and polishing machine is sutable for bevel polishing with its 9 motors and chempering on bevel side edge also with special 2 extra motors. Ske-11B is sutable for various flat glass or mirror with a wide processing range.
the minimum processing glass size 150 mm x 150 mm and the maximum width of bevel can be 50 mm . The controlling manual and semi automatic system are useing for glass thickness,bevel width,angle and processing speed. The convey speed adopts speed adjustment of frequency conversion.
speed-1-10 m/min
minimum glass size-150x150mm(50 x 50 mm-special order)
maximum beveling -50 mm
glass thk. -3 - 25 mm
beveling degree -3-45'9 (as per cliant order)
note: add in above rate 5-10%p&f,transport +18%gst.

Additional Information:

• Pay Mode Terms: T/T (Bank Transfer)
• Production Capacity: 1000 -1500 R.FITS PE DAY
• Delivery Time: 75 DAYS
• Packaging Details: SEPARATE VEHICLE

ske-2epb(5hp) all in 1 semiautomatic double motor machine for glass edge & half / full round polishing and bevening grinding smoothing also glass corner rounding and corner making with changing wheels . machines are available in glass size wise 2. 5x2. 5 /4x4/6x6 fits in single or three phase electrical motors in rang of 2. 5 lakhs to 7. 0 lakhs as per glass table size and attechments.

additional information:

• item code: ske-2epbc
• production capacity: 100 per year
• delivery time: 45-60 days
• packaging details: well packed and despatch by seperate vahical

ske-epb hand glass grinding and polishing machine all in 1 machine manufacturing by
ske-epb(1.5hp)-all shapes glass hand grinding,beveling ,edge rounding corner rounding,tukdi designing and small and medium size glass self grinding machine with single phase motor with both side diamond and polishing wheels with extra rollers, water .as per changing wheels you can do process on all glass edge .

additional information:

• production capacity: 500 pcs, per month
• delivery time: 7 days
• packaging details: as per require

SKE-EPB(2HP)glass hand edge polishing,beveling, 'c'polishing ,og,double og,45' etc all edge processing HAND work on all straight,round,oval,elips,triangle,wave shape,corner rounding etc. With changing require wheels as per glass thickness and shape process on edge like edge polish or c polish or beveling.
machine specifications;
this is horizontal semiautomatic all in 1 machine available with  one or two special motors on which you can fix single ,double or three wheels gather on a shaft so no need to change wheels ,only motor you have  move up and down or forward revers as require
